Weave Design & Dobby Weaving
Pointcarre Weave Design and Dobby weaving software let you create, simulate and produce any kind of checks, stripes and dobby fabric, from the first design idea to on-loom production. Weave Design is the simple way into woven creation, while the Dobby module gives weavers full technical control. Both run natively on Mac and PC in a single application and drive leading weaving looms including Stäubli, Bonas, Müller, Itema, Picanol, Dornier and many others.
Weave Design Software
Weave Design is woven creation made simple : create checks, stripes and woven structures without any technical background.
Design made simple
- Create checks and stripes at the right density
- Draw warp and weft colors directly on the cloth
- Enter colorways as a simple formula
- A library of 4000 weave structures
- Pantone Textile Library included
Woven design without technical requirements
Pointcarre developed Weave Design to allow design studios and style offices to create checks, stripes and simple woven fabrics without technical requirements. It is also the perfect solution for wallpaper designers who want to simulate woven fabric and give their patterns a realistic textile look.
Color at the heart of the process
Color is at the heart of Pointcarre : the colors you pick stay exactly the same throughout the whole creation and development process. You just define the colorways for the warp and the weft, edit the weave blanket, and the simulation updates on screen in real time.
Plaids and stripes in a few minutes
The warp and weft colors can be drawn directly onto the cloth or entered as a formula, so building a plaid or a striped fabric at the right density takes only a few minutes. Weave Design comes with a yarn library, 4000 weave structures and the Pantone Textile Library color picker.
Accurate simulation, fewer samples
You can reference the exact colors of your own yarns and reuse them directly in your designs, then create quick and accurate woven simulations with any kind of yarn, including boucle, chenille, slub and twisted yarns. Irregular densities are taken into account when simulating, so what you see on screen is what you get from the mill. Recognized by prominent textile designers, Weave Design is an ideal tool to present seasonal collections and reduce sampling costs.
Weave Design
Woven creation made accessible
Checks & stripes in minutes
Build plaids and striped fabrics at exactly the correct warp and weft density. Weave Design handles all the technical side for you, so you can focus on color, balance and proportion.
True color from start to finish
Reference the colors of your own yarns and keep them identical across the whole creation and development process, with the Pantone Textile Library included free as standard from day one.
Realistic yarn simulation
Simulate woven cloth with any kind of yarn, including boucle, chenille, slub and twisted yarns. Irregular densities are taken into account on screen for a true, mill-accurate preview.
4000 weave structures
A ready-to-use library of 4000 weaves lets you assemble and preview your fabric instantly on screen, then move smoothly toward clean, production-ready files for the mill.
Dobby Weaving Software
The professional dobby module : create and modify any kind of dobby cloth, at all stages, from design to on-loom production.
Advanced Features
- Warp can be drawn directly on the cloth
- Changes to design viewed on screen in real-time
- Create multiple weaves and double weave fabrics
- Automatic float checking
- Easy input of weave, draft and peg plan data
From design to on-loom production
The Dobby Weave software helps you create and modify any kind of dobby cloth, at all stages, from design to on-loom production. As in every Pointcarre module, color is guaranteed throughout the creation and development process : you define the colorways for the warp and the weft and edit the blanket weave.
Your own yarns and colors
Dobby Weave comes with hundreds of 3D yarns and the main color libraries included, Pantone, Archroma, ColorCSI and the Econyl yarns, so you can reference the colors of your yarns and use them directly in your designs. The warp yarn layout can be drawn directly on the cloth, entered end-by-end or written as measure unit formulas, which makes it quick and easy to create multiple weaves and double weave fabrics, and to build plaids and stripes that adhere to the cloth densities.
Synchronized yarn database
Pointcarre has developed a synchronized yarn database. Register all the necessary data to create a technical card that takes into account the changes of the market, and anticipate the weight of the fabric and its cost. For even more flexibility, weaves can be used as new pegplans simply by dragging and dropping them onto the peg-plan diagram.
Float control and realistic simulation
Dobby Weave lets you check warp and weft floats and make corrections directly on the cloth diagram. Irregular densities are taken into account when simulating, so you can create realistic woven simulations with any kind of yarn and reduce sampling costs.
Automatic plaids & stripes
Generate designs and colorways automatically
- Automatic warp & weft pattern variations
- Generate designs and colorways
- Fast creation of sample blankets
Dobby Weaving
Full technical control for weavers
Automatic weave analysis
Pointcarre automatically calculates the threading layout and the pegplan directly from the weave, and finds the minimal number of shafts needed for the threading, saving you both time and costly mistakes.
Complete spec sheet
Pointcarre issues a complete spec sheet of the cloth that can be fully customized to your own needs and exported to fit straight into your production sheet program, ready for the mill.
Float control & corrections
Check warp and weft floats and make corrections directly on the cloth diagram. Import weaves with drag and drop, then split existing weaves or create double weave fabrics with ease.
Direct loom control
The Dobby module interfaces with all dobby looms : Stäubli, Dornier, Somet, Sulzer, Picanol, CDL and Pignone, the Stäubli electronic punchers, drawing-in machines and the Benninger warping machine.
Yarn Maker
Create custom 3D yarns that behave exactly like real fibers.
Advanced 3D yarn creation
YarnMaker lets designers build custom 3D yarns embedded with hundreds of technical parameters. Each yarn replicates the exact behavior of real fibers, for an unprecedented level of simulation accuracy and realism on screen.
A comprehensive yarn library
Start from an extensive 3D yarn library covering spun yarns such as ring spun, rotor and air jet, plus continuous filament, core and plied constructions, fancy yarns and high-performance technical fibers.
Natural & synthetic fibers
Reproduce natural variations such as cotton, wool, linen and silk, as well as synthetic options like polyester, nylon and advanced polymer fibers, each with its own twist levels and effects.
Stunning visual realism
The result is the world's most advanced textile simulation, combining technical precision with striking visual realism. Every yarn behaves like its real-world counterpart and transforms the accuracy of your design preview.
